Fluid Rotary Unions Overview

Moog's fluid rotary unions are currently used around the world to ensure reliable transmission of life support, process, power and control fluids. Currently, fluid rotary unions rated for pressures up to 15,000 PSI (1000 bar) are available. Seals are selected based on chemical compatibility, design pressure, design temperature, required service life and acceptable leakage rate. Leak collection can be supplied when required for environmental or personnel safety. Fluid rotary unions can be combined with our electrical slip rings and fiber optic rotary joints.

Options

  • Customized mounting and drive configurations
  • Customized materials to satisfy weight, chemical compatibility and other requirements
  • Customized port configurations
  • Hard coating, standard and high pressure FRU, cam be selected for improved abrasion resistance and extended seal life
  • Leakage detection and collection ports (drain to tank)
  • Optional hollow bore

Products

Model Sample Applications Passes Qty/Size Pressure Speed (rpm) Mounting Flange Hollow Bore
70 Diving, Industrial, Scientific ≤ 11
≤ 1 inch
≤ 3000 psi
≤ 200 bar
≤ 10 Standard Optional
134 Seismic 1
≤ 1 inch
≤ 4000 psi
≤ 275 bar
≤ 5 N/A N/A
136 Scientific, Military, Cooling Systems ≤ 5
≤ 1/2 inch
≤ 5000 psi
≤ 345 bar
≤ 1000 Optional Optional
255 Industrial, Military Multiple
1/4 - 1-1/2 inch
≤ 5000 psi
≤ 345 bar
≤ 50 Optional Optional
248 Scientific, Industrial Multiple
≤ 1/4 inch
≤ 1000 psi
≤ 70 bar
≤ 100 Optional Optional
271 Industrial, Military, Scientific ≤ 5
≤ 3/4 inch
≤ 1000 psi
≤ 70 bar
≤ 25 Optional Optional
278 Military Cooling Systems 2
≤ 1/2 inch
≤ 150 psi
≤ 10 bar
≤ 150 Optional Standard
284 FPSO and SPM, Hydraulic Controls Multiple
1/4 - 2-1/2 inch
≤ 15000 psi
≤ 1000 bar
≤ 5 Standard Standard
290 FPSO and SPM Fire Suppression ≤ 2
≤ 3 inch
≤ 200 psi
≤ 15 bar
≤ 5 Standard Standard
The fluid rotary unions listed below can be integrated with AC4598, AC6200 and AC6815 slip rings
301 Industrial 1
1/2 inch
≤ 145 psi
≤ 10 bar
≤ 250 Standard N/A
306 Industrial 1
1/2 inch
≤ 145 psi
≤ 10 bar
≤ 100 Optional 1-1/2 inch
307 Industrial 2
1/8 inch
≤ 145 psi
≤ 10 bar
≤ 200 Optional Standard


Search Products

Typical Applications

  • Marine and life support systems such as saturation diving
  • Training centrifuges for pilots and astronauts
  • Industrial indexing tables
  • Chemical injection systems
  • FPSO hydraulic power and control systems
  • Semiconductor clean room robotics
