Hybrid FORJ

Slide Background

Slide Background

Slide Background

Hybrid FORJs combine an electrical slip ring with a fiber optic rotary joint, allowing electrical, power and optical signal transfer through a single rotational joint.  While fiber optics are becoming the medium of choice for signals due to large bandwidth, immunity to EMI and high reliability, it is acknowledged that rotary interfaces must also carry electrical power.

Contact Our Experts

Jump To:
Products
Related Products

Products

Specifications
H18Singlemode and MultimodeOptic: 1x SM or MM
Elec: 18x Signal
H24Singlemode and MultimodeOptic: 1x SM or MM
Elec: 24x Signal
SRA-73830-[ ]-JXXSinglemode and Multimode
Wide range of electrical options
Multiple circuit configurations
173Singlemode and MultimodeOptic: ≤ 52x SM or MM
Elec: ≤ 7.4 kV, ≤ 720 A Total
176Singlemode and MultimodeOptic: ≤ 52x SM or MM
Elec: ≤ 7.4 kV, ≤ 720 A Total
180Singlemode and MultimodeOptic: ≤ 12x SM and/or ≤ 12x MM
Elec: ≤ 1 kV, ≤ 100 A Total
200Singlemode and MultimodeOptic: ≤ 12x SM and/or ≤ 12x MM
Elec: ≤ 1 kV, ≤ 100 A Total

SM = Singlemode   MM=Multimode
