High Speed Slip Rings
High speed slip rings are used in applications up to 10,000 rpm. Fiber brush contacts provide long-life and operation up to 10,000 rpm without the need for cooling equipment.
| Model | Through Bore | Size: Dia. x L in (mm) | Circuits | Current | Voltage | Operational Speed |
|---|---|---|---|---|---|---|
| PH Series | No | 57.15 - 69.85" L 38.10" OD 1451.6 - 1774.2 967.7 OD |
8 or 12 | 2 amps | 50 V AC |
To 20,000 rpm |
| AC6231 | 1.5" | 4.25" OD x 2.44" L 107.9 OD x 61.9mmL |
8 | 15 amps/ circuit |
220 V AC | 2,500 rpm |
| EC3848 | No | 1.25 x 1.20" 31.75 - 30.5 |
2, 6, 8, 10 | 1 amp | 100 V DC | 10,000 rpm |
| PM Series | No | 132" - 216"L OD 3352.8 OD - 1572.2mmL |
8, 12, 14 | 2.5 amps max. |
50 V AC |
12,000 rpm |
