HIGH DEFINITION (HD) DUAL CHANNEL VIDEO SLIP RING CAPSULE
A slip ring can be used in any electromechanical system that requires unrestrained, continuous rotation while transferring video, power and data from a stationary to a rotating structure.
The SRA-73811 Ethernet slip ring provides dual HD-SDI communication in combination with 4, 2 amp connections. RG179 coax cable is provided for video transfer. The coax cable is supplied terminated with BNC connectors, ready to install.
The SRA-73811 utilizes gold-on-gold contact technology with very low electrical noise for un-paralleled performance and provides functional life that exceeds any competitive slip ring.
For more information about how Moog's ethernet slip rings can fit your specific application, contact our slip ring experts.
- Compatible with:
- SMPTE 259 M (SD-SDI)
- SMPTE 292 M (HD-SDI)
- Speeds up to 250 RPM
- 12, 24, 36 and 48 inch lead lengths
- Available with two coax, and 4, 2 amp connections
- Plug-and-play coax connection
- Lead lengths of 12, 24, 36 and 48 inches
- Flange / no flange
|Operating Speed||250 rpm*|
|Video Connections||HD-SDI / SD-SDI|
|Circuit Options||2 Video, 4, 2 amp|
|Voltage||210 VDC / 240 VAC on standard circuits|
|Temperature Range||-40°C to +80°C|
|Current Rating||2 amp (26 AWG)|
|*Please note that the operational life of the unit is dependent upon rotational speed, environment and temperature.|
- Security cameras
- Rotating video displays
- Camera jibs
- Pan / tilt video camera heads
